Function description: 2019 VW Magotan MQB key matching
Supported products: Launch X-431 IMMO PLUS
Tested models: 2019 VW Magotan MQB, VIN: LFV3A23C6J32***
Procedure:
1. Take IMMO Pro as an example. Enter the VW immobilizer and choose [Anti-Theft Key Matching], as shown in Figure 1.
2. Choose [Key Learning], as shown in Figure 2.
3. Connect the X-431 PROGIII and the connector, and choose OK, as shown in Figure 3
4. Choose [MQB Anti-theft System], as shown in Figure 4.
5. Choose [Platform Mode], as shown in Figure 5.
6. Choose [Dismantle and read anti-theft data], as shown in Figure 6.
7. Choose [View Wiring diagram], as shown in Figure 7.
8. Choose [D70F3529], as shown in Figure 8
The chip model D70F3529 is on the back of the instrument, as shown in Figure 8-1
9. Choose [Pin-up wiring diagram]
10. Use USB to connect the diagnostic connector and tablet device, connect according to the wiring diagram, and select OK
11. After the wiring is successful, choose [Read Chip ID]
12. The chip ID is successfully read and the wiring is normal. Select OK
13. Choose [Back Up Complete Data]
14. Reading the data…Please wait
15. It will read FLASH and EEPROM data in turn, please wait
16. After the data is read successfully, enter the name of the saved file and select OK, as shown in Figure 17 (the Chinese name is not supported for the time being).
17. Select the save path and select OK
18. Confirm the save path and select OK
19. Select [Flash&Eeprom Data Decryption]
20. Select the instrument data read before and select OK
21. The parsing is successful. Record the CS code of the car and select Confirm
22. Choose [Generate Dealer Key]
23. Put the original car key into the programmer and select OK
24. The original car key is successfully read. Put in the blank key that needs to be matched and select OK
25. Choose [VW]
26. The dealer key is successfully generated. Select OK
27. After restoring the instrument, install it on the car, connect the device to the car, and choose [Learn Key]
28. Enter the number of keys to be learned and select OK
29. The current key is a smart key. Select Yes
30. Keep the key in the sensing area on the right side of the steering column and select OK
31. The instrument displays 0-2 and enters the learning mode
32. The first key is successfully learned, and the instrument displays 1-2
33. After the first key is successfully learned, directly replace it with the second key and paste the second key on the sensing area
34. The second key is successfully learned, and the instrument displays 2-2
35. After the data is saved, the function is completed
